Discover Kaxite Sealing's PTFE Extruded Tubing, a versatile high-performance tubing designed for industrial applications. Made from premium PTFE, it offers excellent chemical resistance, durability, and flexibility for seamless fluid handling. Ideal for engineers and manufacturers in chemical, automotive, and medical fields, it ensures reliability in harsh environments. Experience peace of mind with leak-free performance, solving complex sealing challenges. Outperforms competitors with superior extrusion technology and consistent quality. Trust Kaxite Sealing for innovative solutions that drive efficiency and safety.
PTFE extruded tubing is manufactured by high pressure PTFE dispense resin mixed with additive, it is extruded and sintered. According to different demands, the tubing could be opaque or translucent.
PTFE is well known for its chemical resistance, not aging, non stick, self-lubrication, insulation and wide working temperature range from -180 to +260. Because of these excellent properties, PTFE has a wide application in fields of chemical, mechanical, electronics, medical and aviation, etc.
[ Main properties ]
Properties
Unit
Result
Apparent density
g/cm3
2.10-2.20
Tensile strength (min)
MPa
20
Ultimate elongation (min)
%
200
Residual Lubricant Content (max)
%
0.5
Dialectric Strength (min)
KV/mm
10
[ Applications ]
Used as wire and cable jacket, inner lined pipes for corrosive fluids and used in hydrochloric acid heat exchanger, etc.
[ Specifications ]
ODXID(mm)
Tolerance (mm)
ODXID(mm)
Tolerance (mm)
Φ0.8X0.4
0.08
Φ12X10
0.2
Φ1X0.5
0.08
Φ14X12
0.2
Φ2X1
0.08
Φ16X14
0.2
Φ4X2
0.1
Φ18X16
0.3
Φ6X4
0.1
Φ20X18
0.3
Φ8X6
0.1
Φ22X20
0.3
Φ10X8
0.1
Φ24X21
0.3
Hot Tags: PTFE tubing suppliers, Extruded PTFE Tubing manufacturers, High Quality PTFE tubing
